Master Line 8
Performance
Performance and properties depend on size, profile combinations, hardware and infill choices.
Insulation
Thermal insulation - Uf 1 W/m²K
Uw Dependencies
Frame-vent: Ug 0.6W/m²K, warm edge spacer, @1.23x1.48m (104mm sight line), 36mm glass
Thermal insulation - Uw 0.88 W/m²K
Utj Dependencies
Safety
Burglar resistance
RC2 RC3 PAS 24
Impact resistance
I5/E5
Comfort
Air tightness Class 4 (600Pa)
Water tightness Class E900 (900Pa)
Wind load resistance Class C4 (1600Pa)
Durability Class 1 (5000 cycles)
Acoustics - Rw(C;Ctr)
TUTI: 46(0;-3) dB DC: 44(-2;-4) dB
Properties
Max. dimensions & weight
Min. height of vent 600 mm
Max. height of vent 2800 mm
Min. width of vent 450 mm
Max. width of vent 1700 mm
Max. weight of vent 300 kg
Max. weight of glass 1200 kg
Sightlines
Min. frame width (inward opening) 53 mm
Min. vent width (inward opening) 37 mm
Min. frame-vent width (inward opening) 97 mm
Min. frame width (outward opening) 20 mm
Min. vent width (outward opening) 118 mm
Min. frame-vent width (outward opening) 138 mm
Min. width transom profile 50 mm
Depth frame 77 mm
Depth Vent 87 mm
Depth frame-vent 87 mm
Glazing
Glazing method:
Dry glazing / Siliconized glazing / Internal glazing
External glazing / Glazing bead
Rebate height 27 mm
Min. glass thickness - frame/element 4 mm
Max. glass thickness - frame/element 62 mm
Min. glass thickness - vent 13 mm
Max. glass thickness - vent 72 mm
